CE-LBW-48100C
Cworth Energy
Specification:
| Model | CE-LBW-48100C |
| Capacity | 5KWH |
| Voltage | 48V |
| Normal voltage | 51.2V |
| Normal voltage range | 48-57.6V |
| Charge cut-off voltage | 57.6V |
| Discharge cut-off voltage | 48V |
| Max. Charge & discharge current | 100A |
| Recommend Charge & discharge current | ≤60A |
| Normal output power | 3072W |
| Max. Output power | 5120W |
| Communication Port | RS485,CAN |
| Parallel connection amount | 1-6 |
| Ingress protection | IP21 |
| Cycle times | ≥6000@80% DOD, 25°C, 0.5C |
| Working temperature | -10~60℃ |
| Net weight | 63kg |
| Product dimension | 600*490*230mm |
Specification:
| Model | CE-LBW-48100C |
| Capacity | 5KWH |
| Voltage | 48V |
| Normal voltage | 51.2V |
| Normal voltage range | 48-57.6V |
| Charge cut-off voltage | 57.6V |
| Discharge cut-off voltage | 48V |
| Max. Charge & discharge current | 100A |
| Recommend Charge & discharge current | ≤60A |
| Normal output power | 3072W |
| Max. Output power | 5120W |
| Communication Port | RS485,CAN |
| Parallel connection amount | 1-6 |
| Ingress protection | IP21 |
| Cycle times | ≥6000@80% DOD, 25°C, 0.5C |
| Working temperature | -10~60℃ |
| Net weight | 63kg |
| Product dimension | 600*490*230mm |
