CE-LBW-48200C
Cworth Energy
Specification:
| Model | CE-LBW-24300C |
| Capacity | 7.5KWH |
| Normal voltage | 28.8V |
| Normal voltage range | 24-28.8V |
| Charge cut-off voltage | 28.8V |
| Discharge cut-off voltage | 24V |
| Max. Charge & discharge current | 150A |
| Recommend Charge & discharge current | ≤100A |
| Normal output power | 2560W |
| Max. Output power | 3840W |
| Communication Port | / |
| Parallel connection amount | 1-6 |
| Ingress protection | IP21 |
| Cycle times | ≥6000@80% DOD, 25°C, 0.5C |
| Working temperature | -10~60℃ |
| Net weight | 58kg |
| Product dimension | 450*400*272mm |
